Cable Laying Rollers Straight Corner Rollers
| Price: | 500.0 USD |
| Payment Terms: | T/T |
| Place of Origin: | Hebei, China (Mainland) |
|
|
| Add to My Favorites | |
| HiSupplier Escrow |
Product Detail
Means of Transport:
Ocean
Packing:
paper
Production Capacity:
1000set/day
Delivery Date:
7days
Cable Laying Rollers,Straight Corner Rollers
Cable Laying Rollers,Straight Corner Rollers
Cable rollers and cable pulling equipment for the DNO, cable laying contractor and electricity supply industry – this includes straight cable rollers, corner cable rollers, triple cable rollers and specialist cable rollers for pulling underground cables into trenches and ducts up to 33kV.
Cable rollers should always be used when pulling cables.
Straight cable runs are pulled in using straight cable rollers suitably placed in the cable trench to prevent the cable being dragged on the trench bottom or in mud - cable roller spacing is dependent on cable type being laid and the cable pulling tension along the route. Leading cable rollers are used to support the cable over the entire drum width immediately befor being pulled into the trench.
Cable laying applications with bends in the route require skid plates of a radius greater than the cables minimum dynamic bending radius.
Cable Rollers:For cables up to diameter 150mm.
Cat. No. | Rated Load (kN) | Construction | Weight (kg) |
CR0110 | 10 | Cast aluminum frame, aluminum (nylon) roller | 5.4/3.6 |
CR0111 | 10 | Steel tubing frame, aluminum (nylon) roller | 4.5/3.1 |
CR0112 | 10 | Steel tubing, long legs, aluminum (nylon) roller | 5.8/4.2 |
CR0113 | 10 | Steel plate base, aluminum (nylon) roller | 5.5/3.7 |
CR0114 | 10 | Steel tubing frame, aluminum (nylon) roller | 4.7/3.3 |
CR0115 | 10 | Steel tubing frame, aluminum (nylon) roller | 4.7/3.3 |
Corner Roller:Frames of corner rollers are linked together with stake pins to form a suitable bend to guide cables around the corner. (In the right pictures, three corner rollers are linked together)
Cat. No. | Rated Load (kN) | Max. Cable Dia. (mm) | Weight (kg) |
CR0116 | 10 | 150 | 11 |
CR0117 | 10 | 150 | 15 |
Manhole Rollers:Mounted on the verge of manhole to protect cables and pulling ropes.
Cat. No. | Rated Load (kN) | Weight (kg) |
CR0118 | 10 | 10.8 |
Multi-Roller:Used to protect the cable when it enter or run out of a manhole. Easy to use.
Cat. No. | Rated Load (kN) | Weight (kg) |
CR0120 | 10 | 10.8 |
Multi-Roller:Used to protect the cable when it enter or run out of a manhole. Easy to use.
Cat. No. | Rated Load (kN) | Weight (kg) |
CR0125 | 80 | 3.3 |
CR0126 | 90 | 3.5 |
CR0127 | 100 | 3.8 |
CR0128 | 130 | 6 |
CR0129 | 150 | 7.2 |
